Categorías: · ACCESORIOS P/REMOLQUE, · TIJERAS (HOIST)
DESCRIPCIÓN:
- PERNO LISO DE ACERO DE ALTA RESISTENCIA CON PASADOR DE ARO
MEDIDAS:
- DIÁMETRO DEL PERNO DE 1″
- LONGITUD TOTAL DEL PERNO DE 3 1/2″
- ORIFICIO PARA PASADOR DE 23MM
- PASADOR DE ARO, 1-9/16″ DE LARGO, 3/16″ DE DIÁMETRO
DESCRIPCIÓN:
- CAPACIDAD DE 5,000 LBS
- CON ORIFICIOS DE MONTAJE
- MATERIAL: HIERRO
MEDIDAS:
- DIÁMETRO INTERIOR DEL ARO DE 1 1/4″
- MEDIDAS EXTERIORES: 4 1/2″ X 4 7/8″
- LOS ORIFICIOS DE MONTAJE MIDEN 3″ X 3 1/4″ DE CENTRO A CENTRO
- REQUIERE 7/8″ POR DEBAJO DE LA SUPERFICIE DE MONTAJE
- ZINCADO PARA RESISTENCIA A LA CORROSIÓN
- NO INCLUYE HERRAJES DE MONTAJE
DESCRIPCIÓN:
- KIT DE BUJES UNIVERSAL PARA TIJERA (516, 521, 620, 621)
- FABRICADOS CON ACERO DE ALTA CALIDAD (SIN COSTURA)
- CUENTAN CON ORIFICIO PARA GRASERA DE 1/4″ (DE ROSCA)
- MAQUINADO PRECISO Y DE CALIDAD
- DIMENSIONES: 3.25″ X 4.25″
- REQUIERE 4 ORIFICIOS DE 5MM
- MECANISMO DE BLOQUEO INCORPORADO
- FABRICADO CON ACERO INOXIDABLE RESISTENTE A LA CORROSIÓN
- PUEDE USARSE PARA GRAN VARIEDAD DE APLICACIONES, INCLUIDAS PUERTAS DE CAJAS DE HERRAMIENTAS Y REMOLQUES
DESCRIPCIÓN:
- PARA BOLA DE ENGANCHE DE 2 5/16″
- FABRICADO CON ACERO DE ALTA RESISTENCIA
- CUBIERTA DE ACERO PULIDO COLOR PINTURA BASE COLOR GRIS
- PESO: 20.50KG
MEDIDAS:
- DIÁMETRO INTERIOR: 3 1/2″
- DIÁMETRO EXTERIOR: 4 1/2″
- DIÁMETRO DEL PERNO: 3/4″
- LONGITUD COMPRIMIDA (DE CENTRO A CENTRO): 10.25”
- LONGITUD EXTENDIDA (DE CENTRO A CENTRO): 15.25”
- SUJECCIÓN DE BOLA DE NAILON DE 10 MM
- CAPACIDAD: 90LBS
DESCRIPCIÓN:
- ACOPLADOR (JALÓN) AJUSTABLE, DE 2 5/16″ RAM, CAPACIDAD DE 15,000 LBS
ESPECIFICACIONES:
- PARA BOLA DE ENGANCHE DE 2 5/16″
- PARA CANAL “C” DE 3″
- CAPACIDAD DE 15,000 LBS
LOS ACOPLADORES RAM ESTÁN 100% EQUIPADOS CON BOLAS PARA GARANTIZAR UN AJUSTE ADECUADO CUANDO EL ACOPLADOR SE CONECTA A UNA BOLA DE ENGANCHE. LOS PESTILLOS DEL ACOPLADOR ESTÁN CONFIGURADOS PARA UN FÁCIL ACOPLAMIENTO Y DESACOPLAMIENTO. LOS ACOPLADORES ESTAMPADOS INCLUYEN TODOS MARCAS REQUERIDAS POR SAE Y CUMPLEN CON EL ESTÁNDAR J684. LOS ACOPLADORES AJUSTABLES VIENEN CON PERNOS ESTÁNDAR DE GRADO 8 CON TUERCAS Y ESTÁN CONFIGURADOS PARA UN CANAL DE 3″ ESTÁNDAR DE LA INDUSTRIA.
APLICACIONES:
- INSTALACIONES DONDE SE REQUIERA SELECCIONAR EL FLUJO HIDRÁULICO HACIA 5 DISTINTAS VÍAS.
- LONGITUD COMPRIMIDA (DE CENTRO A CENTRO): 7”
- LONGITUD EXTENDIDA (DE CENTRO A CENTRO): 10”
- SUJECCIÓN DE BOLA DE NAILON DE 10 MM
- CAPACIDAD: 30LBS
- LONGITUD COMPRIMIDA (DE CENTRO A CENTRO): 8.5”
- LONGITUD EXTENDIDA (DE CENTRO A CENTRO): 12”
- SUJECCIÓN DE BOLA DE NAILON DE 10 MM
- CAPACIDAD: 120LBS
